6mm diameter
Direct view 0°
360-degree articulation
1280×720 pixels
Optical fiber illumination
10-100mm depth of view
5.5″ touch screen
The 6mm inspection probe is built for versatility, delivering exceptional imaging clarity in a wide range of industrial inspections.
The 6mm probe provides wide viewing angle up to 1280*720 pixels.Our powerful Optical Fiber lighting deliver bright, clear visuals, very durable.
It has a wide range of applications and can be used in a variety of endoscope detection scenarios. Such as Automobile Manufacturing, Medical Pipeline, Mechanical Casting, Precision Casting, Aerospace, Aviation, Energy Power, Special Tubes and Drug Control.
T2 series is an intelligent videscope designed specifically for industrial non-destructive testing. It is based on multiple interchangeable probes from ultra-fine 1.0mm to 8.0mm and a unified intelligent system to create a high efficiency and easy-to-operation industrial device.
Ultra Fine Display
5.5-inch full HD touch screen (1920×1080), can be readable under the sun
Precision Control
The original mechanical joystick + touch dual-mode system realizes 130°±10° active joint steering, leaving no blind spots
One Device Compatible For Multiple uses
The whole series is compatible with probes of different diameters such as 1.0mm/1.2mm/1.7mm/2.2mm/2.8mm/3.0mm/3.9mm/6mm/8mm, with its fast exchange system, you could change the probes within 5 seconds.
Industrial-grade Reliability
The probe has IP67 protection + more than 99% tungsten steel cable, which can withstand harsh environments such as oil pollution, complicated temperature (-10℃~50℃), and vibration;
Intelligent Efficiency Enhancement
Built-in distortion correction/comparison measurement tools, support defect annotation and data export with Type-C and HDMI cable, and greatly improve the efficiency of standardized inspection.
Long Battery Life
Intelligent power system with rechargeable high-density lithium battery, could offer at least 4h running time, full power supports full inspection of 8-10 engine cylinders (actual test conditions)
| Monitor | |
| Dimensions / Weight | 182 x 336 x 88 mm / 1.5 kg |
| Display Screen | 5.5″ LCD touchable screen with 1920 x 1080 resolution |
| Control System | Mechanical joystick, 360-degree rotation |
| Functions | Noise reduction, distortion correction, comparative measurement, image capture, video recording, playback, articulation, illumination control |
| Image Control | Zoom, image and video playback, freeze-frame, flip image |
| File Management | Auto or manual file folder creation, rename files, remark photos |
| Brightness Control | 7 level adjustment |
| Operating System | Real-time multifunctional operating system |
| Operating Method | Touch screen and press button |
| Language | 3 Languages |
| White Balance | Automatic or manual |
| Exposure Mode | Automatic |
| Firmware Update | Via SD card service pack |
| Image Format/Video Format | JPEG, AVI |
| I/O port | SD card, HDMI port , Type-C |
| Power | Rechargeable lithium-ion battery, 4h long running time |
| Storage | 32 GB high-speed SD card (Up to 128 GB） |
| Full System | Monitor, insertion probe, charging adapter, HDMI cable, Type-C cable, 32 GB SD card, SD card reader |
| Compatibility | Interchangeable probes for all T2 series |
| Working Temperature | -10ºC to 50ºC (14ºF to 122ºF) |
| Storage Temperature | -20º to 60ºC (-4ºF to 140ºF) |
| Relative Humidity | 90% max, non-condensing |
| Defence | Insertion tube and probe:IP67 Monitor: IP55 |
| Insertion Probe | |
| Diameter | 6mm |
| Resolution | 1280 x 720 pixels |
| Direction of View | Direct 0° |
| Depth of Field (DOF) | 10 – 100 mm |
| Field of View (FOV) | 120° |
| Illumination Source / Type | Optic Fiber / LED / White |
| Probe Articulation Range | 130°±10° |
| Cable Material | Tungsten Steel |
| Probe Material | Stainless Steel |
| Probe Length | 9mm |
| Cable Length | 1/1.5/2/3/5/8m |
| Place of Origin: | Wuxi City,Jiangsu Province |
| Brand Name: | Kunscope |
| Certification: | ISO9001,CE |
| Model Number: | T2J60D |
| Minimum Order Quantity: | 1 |
| Price: | Request a quote |
| Packaging Details: | 1 set in a case |
| Delivery Time: | Generally it is 5-8 working days if the gods are in stock, or it is 15-20 working days if not in stock.It is according to stock quantity situation. |
| Payment Terms: | 100% TT in advance |
